CATIA-connected BOMs
BOM extraction and review with rough-stock measurement and Smart Setup decisions captured per row.
S2 — CAD Automation / Engineering Workstation
CADMation NXT. Engineering data that survives the handoff.
The native Windows successor to CADMation: a workstation for CAD BOM extraction, CATIA-connected engineering inputs, rough-stock measurement, Smart Setup decisions, drafting automation, exports — and durable .cadm project packages built for engineering-to-production transfer.
CATIA
.CADM
BOM REVIEW
SMART SETUP
DXF / PDF / EXCEL
Product Direction
One project package instead of scattered files.
BOM rows, measurement decisions, drawings, exports, and production notes usually live as scattered files. The .cadm package keeps project identity, BOM review, decisions, drawings, artifacts, and mobile-transfer data together — so what engineering decided is what production receives.
What It Connects
CAD logic, drawings, and production transfer.
NXT separates the operator screen from the processing engines behind it. CATIA, FreeCAD, OCCT, and proven legacy tooling logic run behind controlled worker jobs — the user sees reviewed outputs instead of brittle manual steps.
Drafting automation
Drawing generation and exports — DXF, PDF, Excel — produced from the same reviewed project state.
Engine boundary
CAD engines run as isolated workers with bounded diagnostics — stability by architecture, not by luck.
Product Status
Built with careful release checks.
CADMation NXT is under active Saptasati development, tested through installer checks, fresh-machine trials, toolroom trials, and output comparisons before broader production use is claimed. No shortcuts — the same release discipline we expect of a tool leaving the shop.
