CADMation Mobile. Engineering details beyond the workstation.

The Android-facing review tool for job packets: session details, 3D models, 2D drawings, BOM data, hole tables, measurement history, and shop-floor engineering checks — where teams inspect, discuss, and correct parts.

ANDROID 3D REVIEW 2D REVIEW BOM MEASUREMENT HISTORY SHOP-FLOOR CHECKS

Field Workflow

A mobile companion for CAD-driven manufacturing.

The mobile app is aimed at the gap between engineering workstations and shop-floor decisions. It supports CAD review and measurement where the parts actually are — beside a VMC, at an inspection table, during a vendor call.

Viewer Depth

Built for CAD usability, not just file thumbnails.

M-01

3D Review

CAD-style render modes, lighting presets, orthographic/perspective controls, sectioning, quick views, and measurement history.

M-02

2D Drawings

Pan, zoom, drafting grid, paper/title controls, measurement locks, and saved review state.

M-03

Job Details

Session details, BOM rows, drawings, hole tables, and review screens organized around each work packet.

M-04

Development Focus

Next steps include production geometry intake, dependable backend sync, and exportable measurement packs.

Relationship To PartLens

Mobile carries job packets; PartLens opens anything.

CADMation Mobile is the richer job-review tool for Saptasati programs. PartLens is the simpler free viewer for anyone who needs to open and measure STEP/STP files without a CAD seat, login, upload, or workstation.
